Tensile structure corner fittings are the multi-plate nodes used where two or more membrane edges, cables and steel members meet at a corner - the high-stress point of a tensile roof. The fitting is a welded, laser-cut stainless assembly: a main node plate with drilled holes for each incoming cable, edge clamp or bracket, plus gussets to carry the concentrated load. At a corner the forces of several edges meet at once, so the plate thickness, hole layout and weld group are what keep the node from punching through the membrane. It is the engineered meeting point of a tensile structure.
Because no two tensile corners are alike - the angles, cable count and load path differ on every plan - we fabricate each corner fitting from your structural drawings. The laser cutter sets the node plate profile and hole coordinates, the welding robot builds the gussets, and precision machining finishes every bolt bore. We support a prototype corner for fit-up before the full run, so the angles and hole positions are proven on site. The buyer gets a corner node that matches the geometry of the plan exactly - each incoming edge lines up without shimming or re-drilling.
Specifications
|
Item |
Detail |
|
Material |
Stainless steel 304 / 316L |
|
Type |
Multi-plate welded node with gussets |
|
Application |
Tensile roof & facade corner nodes |
|
Custom Options |
Plate thickness, hole layout, connection count, grade |
|
Custom Dimensions & Specifications |
Non-standard product - all dimensions, tolerances and finishes are manufactured to customer drawings and customized per project requirements |
Applications
Roof corners where membrane edges meet. The node gathers several edge forces into one thick plate, preventing the local tear that corners are prone to.
Cable crossover points on sails. Drilled holes for each incoming cable let a sail corner pull in several directions at once without bunching.
Column head corners. Gusseted nodes transfer corner loads into the column head, with consistent welds for predictable strength.
Customization
We build to your drawings: node plate profile and thickness, number and layout of connection holes, gusset arrangement, and stainless grade. Prototypes and OEM/ODM supported.
Packaging & Transportation
All parts are wrapped with custom EPE foam to protect corners and surfaces, then packed in sturdy, fumigation-free plywood crates or galvanized steel crates for safe international shipment. Trade terms: EXW and FOB.
FAQ
Q: What is your sample policy?
A: Sample development takes 7–15 days. Samples are free if the value is under 1,000 RMB. Mass production strictly follows the approved sample.
Q: Do you accept 3rd-party inspections?
A: Yes, we accept third-party inspections and perform 100% inspection before packing if required.
Q: How do you ensure on-time delivery?
A: Through scientific scheduling, pre-locking raw materials, and an automated early-warning system for every production stage.
